Custom Mulit Button Tactile Membrane Switch Keyboard Without Metal Dome Inside

  • 1
  • 2
  • 3

Brand Name : Zhongshan

Model Number : ZS-99

Certification : ROHSISO9001,2000

Place of Origin : Jiangsu(China mainland)

MOQ : 100 pie

Payment Terms : 30% deposit, the 70% balance after shipment or full payment before air transoportation

Supply Ability : 50000 pieces per week

Delivery Time : within one week after receiving order payment

Packaging Details : Seal plastic bags with carton boxes or due to customer detail requirements

Keypad Button : PET/PC/PMMA

Name : flexible membrane keyboard

application : printer machine

brand name : Zhongshan

Feature : Water-proof

Size : 90*105mm

Contact Now

custom tactile membrane keyboard membrane switch / ZS-99 /

90*105mm switch with out metal dome inside


Specification



1, operating voltage:


 ≤ 35VDC


2, working current:


 ≤ 100mA


3, Contact resistance:


 0.5 ~ 5Ω


4, Insulation resistance:


 ≥ 100MΩ (100VDC)


5.Spring Time


 ≤ 6ms



6.Switch Stroke


 Flat 0.1~0.5mm
Tactile 0.6~1.5mm


7.Operation Force


 Flat 57g~286g
Tactile 170g~398g


8.Operation Temperature


 -20℃~ +80 ℃


9.Storage Temperature


 -40 ℃ ~ +85 ℃ temperature of 95% ± 5%


10, atmospheric pressure:


 86 ~ 106kDa



11.Life expectancy



 Flat 500Million-1000Million
Tactle 100million




Membrane Switch Advantages:

1. Beautiful appearance ,rich and bright in color.

2. Small size ,light weight ,good tactility.

3. Low cost ,high lifespan.

4. Easy to operate ,intuitive ,safe and reliable ,In-house 100%functionally tested.

5. Customized specification is available and keys can make different shapes.



What Is A Membrane Switch?

Membrane switches are generally made from five different layers. This includes membrane,

graphic, tactile, rigid and static layers. The first layer contains the graphic interface for the

user to control the machine. It can also include a flexible circuit for less expensive

alternatives. Another layer will contain the printed circuit which allows a signal to be

transmitted. The ink that is used for the printing on the circuit is generally made up of a

variety of metals. This helps for the signal to be conductive for turning on and off. Membrane

switches allow for communication to take place in electronic devices. Membrane switches are

a piece of equipment that can be highly sophisticated or rather simple by design.

Custom Mulit Button Tactile Membrane Switch Keyboard Without Metal Dome Inside


Custom Mulit Button Tactile Membrane Switch Keyboard Without Metal Dome Inside


Packaging & Shipping

Custom Mulit Button Tactile Membrane Switch Keyboard Without Metal Dome Inside
